  • High Precision Series Printed Armature Servo Motor
  • 9cm Armature
  • Compact Construction
  • Zero Cogging - Ultra Low Velocity Ripple
  • Brushed DC Motor incorporating Neodymium Rare-Earth Magnet Technology
  • Custom Shaft & Housing Configurations Available
  • Gearbox, Brake, Encoder & Tachometer Options
Unit of Measure

Voltage

 N/A 22 V

Torque

 N/A 36 N·m

Power

 N/A 113 Watts

Speed

 N/A 3000 rpm

Current

 N/A 8.7 A

N/A Servo mechanisms, motion control, industrial robots, CNC machining, printing machinery, logistics solutions, medical mobility, medical scanners, flight simulators, marine autopilots and high ambient temperature ventilation.

N/A Industrial automation, automotive, medical, life sciences, aerospace, printing, logistics, instrumentation, test and measurement, oil & gas and offshore marine.

N/A

  • Round shaft
  • Extra slats
  • Length variants
  • Cut gear
  • Other modifications
  • High altitude
  • Vacuum
  • High temperature
  • EMC suppression
  • Long leads
  • Connectors
  • Tri-rated cable
  • Rated for operation in 150°C ambient
